Anderson Red PP180A Housing

$10.50

Anderson PP180A Housing for up to 1/0 BS cable. This is a single pole heavy duty connector for cable from 10 to 1/0 AWG. Amp rating of 150.1 – 500.0A.

8 in stock

SKU: AH0383 Category:

Anderson Powerpole Red PP180A Housing 1 Way

The 180 Amp Powerpole is for single cable connection.

Suitable for cable sizes up to 1/0, these connectors have sleeves on the sides allowing for the connectors to be joined and blocked as needed.

Specifications

Amperage Rating: 150.1 – 500.0A
Colour: Red
Housing Gender: Genderless
Housing Material: Polycarbonate
Mounting Type: Cable
Oper. Volt (AC): 600
Oper. Volt (DC): 600
Positions: 1
RoHS: Yes
Wire Size (AWG): 10-1/0

Please note, select the colour option and also the pins option to select your requirement.

When ordering Powerpoles the pins selection includes only 1 pin per housing.

Color

Red, Black

Contacts

None, 175/180 2/0 contact each, 175A 1/0AWG contact each, 175A 1AWG contact each, 175A 2AWG contact each, 175A 4AWG contact each, 175A 6AWG contact each
